STANDARD FEATURES
· Boom and wheel support
· Chain and secure straps
· Swivel rear caster
· Towbar
· Foam-filled Tires
· Skydrol resistant paint
· All non-painted parts are plated for corrosion resistance
· Parking brake
· Storage Box
· 2 year standard warranty
OPTIONAL FEATURES (Add suffix to model #)
4C: Brake Cradle (see below) PN: 331090
5C: Brake Cradle (see below) PN: 331088
CSP: Customer specified paint color
PACKAGING OPTIONS (Add suffix to model #)
KD: Unit shipped knocked down domestic skid (incl)
ECKD: Unit shipped knocked down international crate
SPECIFICATIONS | STANDARD | METRIC |
Wheel and Brake Dolly Capacity | 700 lbs. | 318 kg |
Boom Lift Capacity | 500 lbs. | 227 kg |
Main Unit Weight | 500 lbs. | 227 kg |
Tire dia. capacity | 30”-56” dia. | 762mm-1423mm dia. |
Overall Dims | 56” W x 70” L x 38” H | 143 W x 178 L x 97 H (cm) |
Lift Height | 26 in | 660 mm |
Ground clearance | 4 in | 102 mm |
Maximum Towing Speed | 5 mph | 8 km/h |
Approximate Net Weight | 500 lbs | 227 kg |
Cradle Weight | 40 lbs. | 18 kg |
Cradle capacity | 600 lbs. | 272 kg |
CRADLE | NOSE WHEEL | MAIN WHEEL |
4C PN:331090 | A300, A310, A319, A320, A321, B707, B727, B737, B757, B767, DC8 | A300, A310, A319, A320, A321, B707, B717, B727, B737, B757, B767, DC8, DC9, MD80-90 |
5C PN:331088 | A330, A340, B747, B777, DC10, MD11, L1011 | A330, A340, B747, B777, DC10, MD11, L1011 |
